Brand Name : TEYI
Model Number : KP-10
Certification : CE/API/ISO/TS
Place of Origin : China
MOQ : 1-10PCS
Price : negotiation
Payment Terms : L/C at sight, T/T, Westem Union
Supply Ability : 5000PCS per month
Packaging Details : Packed in carton firstly, and then reinforced with wooden case for outer packing
Product Name : Quickly Exhaust Valve
Material : Cast Iron
Size : DN15 to DN150
Pressure : PN6 to PN16
Connect End : RF, FF
Medium : Water, Oil. Gas, Steam
Working Temp. : 0 to 180 ℃
Inspection Standard : GB/T13927
Stainless Steel Air Vacuum Release Valve Pneumatic 1 Quick Exhaust Valve
Products Description
Quickly Exhaust Valves function to release air pockets that collect at each high point of all pressured pipeline. Exhaust VAlves can open against internal pressure, because the internal lever mechanism multiplies the float force to be greater than the internal pressure. This greater force opens the orifice whenever air pockets collect in the valve. Exhaust Valves are essential for pipeline efficiency and water hammer protection.
Exhaust valve was installed on the top of pipeline to relief the air of pipeline.
Main part material
No. | Name | Material |
1 | Body | Cast Iron/Stainless Steel |
2 | Bonnet | Cast Iron/ Stainless Steel |
3 | Ball | Stainless Steel |
4 | Yoke | Stainless Steel |
5 | Yoke | Brass/Stainless Steel |
We are committed to offering porducts that meet a wide range of appications and requirments. We continually improve our product line by introducing new products and enhancing exsiting designs. Providing our customers with the best quality on the market.
![]() |
Stainless Steel Air Vacuum Release Valve Pneumatic 1 Quick Exhaust Valve Images |
